CERTIFICATIONS

TREM 3 certification engine

CMVR certification power tiller for transportation

ICT test passed for subsidy approval

Samyak's AST makes it work under any soil conditions
Aesthetically designed and sturdily built for rough conditions
The TRUE HP feature guarantees 12 HP true power at incredibly low fuel consumption
Changeable cage wheel to suit all soil conditions
Suitable for de-weeding Sugarcane, Banana and Cotton farms
The riding comfort is enhanced by a pneumatic rear wheel and driver friendly seating
Known for its endurance on the field working long hours without break
Easy availability of spare parts
Low on maintenance, a cost that is almost 1/3rd of other Tillers in the market
Suitable for pumping water and spraying pesticides
Facility for attaching trailer
The first of its kind 100 percentage indigenous tiller with seat approved by SRFMTTI, Government of India

Model	ST 960
Type	Single Cylinder, DI 4 Stroke Horizontal Engine
Air Filter Type	Oil Bath
Cooling System	Water Cooled Thermosyphon
Engine Power	12 HP
CC	744 cc
Lubrication	Gerotor Pump
Engine Oil Capacity	3 Lts (SAE 40)
RPM	2000
Fuel Tank Capacity	11 Lts
Radiator Capacity	5 Lts
GEAR BOX
Type	Sliding Mesh
Forward Speed	6
Reverse Speed	2
Blade Speed	2
Power Transmission	Belt, Gears, Chain
Gear Oil	5 Lts (SAE 90)
Aux. Gear Oil	0.800 ml (SAE 90)
Rotary Oil	1.5 Lts
ROTORY
Tilling Width	600 mm
Tilling Depth (Max)	200 mm
Blade	20 Nos (10+10)
Tilling Capacity	1.2 Acres / 4 Hrs
Tyre Size	700 Std, 590, 530 mm
Ground Clearance	200 mm
Overall Length x Width	2910 mm x 920 mm
Kerb Weight	524 Kg
Max. Travelling Speed	15 Kmph

Mud Wheel

Tail Wheel

Seating System

Tail Wheel Skid
